Electro Hydraulic Orange Peel Grab Bucket For Solid Waste Handling
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI |
| Certification: | ABV/BV/CCS |
| Model Number: | 3 cube meter |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 30000-100000 |
| Packaging Details: | nude |
| Delivery Time: | 15 days |
| Payment Terms: | T/T, L/C, Western Union, MoneyGram |
| Supply Ability: | 300 set/y |
|
Detail Information |
|||
| Material: | Carbon Steel | Wear Plate: | Hardox Or NM400 |
|---|---|---|---|
| Model: | 1-1.5 Cube Meter | Color: | Red |
| Painting: | Jotun | Character: | Electric Hydraulic |
| Feature: | Reliable And Durable | Type: | Orange Peel Grab |
| High Light: | Electro Hydraulic Powered Grab Buckets,Solid Waste Handling Orange Peel Grab,Hydraulic Clamshell Grab Orange Peel |
||
Product Description
Electro-hydraulic orange peel grab bucket for solid waste handling
Electro-hydraulic Orange peel grab is accurately controlled by hydraulic technology, which can be used for serious component pollution, bulk material sites where mechanical clamps are prone to jamming plugging, and corrosion. It is mainly applicable to the use of hazardous solid waste, chemical raw materials, and other sites, such as garbage power plants, hazardous waste treatment centers, solid waste landfill sites, sludge disposal sites, etc.
Electro-hydraulic orange peel grab buckets for solid waste handling are specially designed for handling waste handling according to the client`s application situation.
Technical specification
| Electro-hydraulic Orange peel grab | |||
| Project | unit | SSI 11-1 | SSI 15-1.5 |
| Volume | m3 | 1 | 1.5 |
| Close height A | mm | 2280 | 2590 |
| Open height B | mm | 1940 | 2230 |
| Close width C | mm | 1750 | 2070 |
| Open width D | mm | 2630 | 2920 |
| Nubmers | 6 | 6 | |
| closed form | Full closed | Full closed | |
| Closing time | sec. | 11 | 11 |
| Opening time | sec. | 9 | 9 |
| Dead weight | kg | 1700 | 1950 |
| Control mode | valve control | valve control | |
| Motor rating | kw | 11 | 15 |
General drawing
