Longitudinal Stockyard Cantilever Slewing Stacker For Stacking Bulk Material
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI-ZHIGO |
| Certification: | manufacture certificate |
| Model Number: | Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | US $500,000-1,000,000/ Set |
| Packaging Details: | Wooden case or bare |
| Delivery Time: | 6 months after receipt of advance payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 40 sets / year |
|
Detail Information |
|||
| Product: | Cantilever Slewing Stacker | Painting: | Jotun |
|---|---|---|---|
| Color: | Red | Capacity: | 2000 T/h |
| Steel Work: | Welding | Component: | High Quality |
| Price: | Low Cost | Material: | High Quality Steel |
| High Light: | Stockyard Cantilever Slewing Stacker,Bulk Material Slewing Stacker,Cantilever Longitudinal Stockyard Stacker |
||
Product Description
Cantilever rotary stacker in Longitudinal Stockyard Stockyard Stacking System Stacking System for Stockyard
Applications
The slewing cantilever stacker is mainly used for stacking limestone, sandstone, raw coal and other bulk materials. It is mainly used for storing and blending materials in stockyard. It is mainly applicated for metallurgy, mining, building materials, chemical industry, cement and other industries.
Feature
The slewing cantilever stacker has the advantages of simple structure, reliable performance, easy operation, convenient maintenance and safe operation.
The slewing cantilever stacker can stacking operation to different material pile, and to stack a variety of materials, meet different stacking processes requirement. The slewing cantilever stacker was design as compact, electric-hydraulic driven with automatic operating function without man power.
Table of equipment parameters
| description | parameter | unit |
| material | ore,sandstone,raw material | |
| density | 0.8~2.2 | t/m3 |
| granularity | <70 | mm |
| moisture | <2 | % |
| stacking capacity | 100~5000 | t/h |
| rail span | 4~8 | m |
| slewing radius | 15~40 | m |
| slewing angle | ±100 | ° |
| width of belt | 500~1800 | mm |
NOTICES
The customer shall provide the following information when place order
- character of bulk material;
- Stockyard information;
- Process flow chart;
- Power supply;
- Communication and control requirements
