5000 Tph Capacity Stacking And Reclaiming Equipment For Bulk Materials Handling
Product Details:
| Place of Origin: | China |
| Brand Name: | SSI-HDCZ |
| Certification: | manufacture certificate |
| Model Number: | Customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | US $500,000-5,000,000/ Set |
| Packaging Details: | Wooden case or bare |
| Delivery Time: | 6 months after receipt of advance payment |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 40 sets / year |
|
Detail Information |
|||
| Description: | Stacker And Reclaimer | Painting: | HEMPEL |
|---|---|---|---|
| Color: | Blue | Capacity: | 5000 T/h |
| Character: | Durable | Motor: | ABB |
| Benefit: | Low Cost | Location: | Stockyard |
| High Light: | 5000 Tph Capacity Coal Reclaimer Stacker,Stacker Reclaimer Bulk Materials Handling |
||
Product Description
5000 tph capacity stacking and reclaiming equipment for bulk materials handling
1. Summary introduction
Bucket-wheel stacker reclaimer can perform the functions of continuous stacking, taking, mixing, and storage of bulk particles and block raw materials. It is widely used in the material storage and transportation system of electric power, metallurgy, building materials, chemical industry, port, coal, grain, and other industries. It is common equipment in large and medium-sized industrial enterprises.
Bucket-wheel stacker reclaimer is mainly composed of bucket wheel, slewing, boom raising, walking, cantilever belt conveyor, and metal structure, tail car, auxiliary structure, central hopper, spray dust suppression system, lubrication system, electrical system, power supply device, and so on.
By adjusting the tail car structure (fixed single tail car, semi lying tail car, full lying tail car, cross tail car, double tail car, etc.), the bucket wheel stacker reclaimer can realize many functions, such as stacking, reclaiming through, reclaiming turn back, shunting, through and so on, to meet the requirements of different working conditions.
2. Structural form of the whole machine
The medium and small bucket wheel machines adopt the overall balance form, with few movable hinge points and a low failure rate. The central hinge seat of the superstructure is equipped with lubrication-free joint bearing, with less maintenance workload. For large bucket wheel machines, the movable balance type is mostly adopted, mainly considering that the pitching angle of the cantilever frame is small and the change of the center of gravity relative to the superstructure is small.
Features
| description | Stacker and Reclaimer |
| painting | HEMPEL |
| color | blue |
| capacity | 5000 t/h |
| character | durable |
| motor | ABB |
| benefit | low cost |
| location | stockyard |
GA (fixed split tripper car)
GA (full function tripper car)
3. Main parts
1. traveling system
2. Bucket wheel system
3. Luffing mechanism
4. Slewing system
5. Cantilever belt conveyor
6. Upper metal structure
7. Tripper car
8. Cable reel
