Product Details:

Place of Origin: China
Brand Name: SSI
Certification: mill certificate
Model Number: customized

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD 10000-60000
Packaging Details: nude
Delivery Time: 120 days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 220 set/ year
Get Best Price Contact Now

Detail Information

Product: Curved Belt Conveyor System Color: Orange
Type: Convention Painting: HEMPEL
Character: Long And Curved Surface Treatment: SA2.5
Price: Reasonable Motor: Seimens
High Light:

Bulk Material Curved Conveyor Belt

,

Curved Belt Driven Conveyor

,

Convention Conveyor Belt System

Product Description

Tailor-made long-distance curved belt conveyor system for bulk material conveying



Shanghai Sunshine industry technology co., Ltd has been designing and supplying client bulk materials conveying systems for industries around the world for the past six years. Whether you are looking for a piece of equipment or a complete turnkey system, we are happy to offer you a customized solution, just customized to your specification requirement. We can provide bulk material handling systems for both new projects and existing systems. It`s used for handling comment material such as coal, clinker, aggregates, biomass products grain gypsum, iron ore, limestone, sulfur.

Trough belt conveyor, flat belt conveyor, climbing belt conveyor, turning belt conveyor, telescopic belt conveyor, and other forms. Lifting baffle, skirt, and other accessories can also be added to the conveyor belt to meet various process requirements. Both sides of the conveyor are equipped with a workbench and light frame, which can be used as an assembly line of belt conveyors such as electronic instrument assembly and food packaging.



specification of standard conventional conveyor belt



Model Capacity(t/h) Belt width(mm) Speed(m) Max distance(m) Power of Motor(kw)

Diameter of pulley(mm)



Diameter of roller(mm) Max incline angle(°)
DTS80/40/2*40S 400 800 2 800 2*40 500 89 +18
DTS80/40/2*55S 400 800 2 800 2*55 500 89 +18
DTL80/40/90S 400 800 2 1000 90 630 108 +18
DTL80/40/2*40 400 800 2 800 2*40 500 89 +18
DTL80/40/2*55 400 800 2.5 800 2*40 630 89 +18
DTL100/63/2*75S 630 1000 1.9 1000 2*75 630 108 +18
DTL100/80/160S 800 1000 2.5 1000 160 630 108 +18
DTL100/80/2*160S 800 1000 2.5 1500 2*160 630 108 +18
DTL120/120/2*160S 1200 1200 2.5 1000 2*160 800 133/159 ± 5
DTL120/120/2*200S 1200 1200 2.5 1000 2*200 800 133/159 +18
DTL120/150/2*160S 1500 1200 3.15 1500 2*200 800 133/159 +18





Photos of our factory

Bulk Material Curved Belt Conveyor System Long Distance 0

Bulk Material Curved Belt Conveyor System Long Distance 1

Bulk Material Curved Belt Conveyor System Long Distance 2

Bulk Material Curved Belt Conveyor System Long Distance 3
